ObservationMeasurementResultPNSD

ObservationMeasurementResultPNSD

Attributes 

Attribute Code	Attribute Name	SQL DB Data Type	ReportNet3 Data Type	Properties	Code list	Related table(s)	In Reporting
OMP_01	CountryCode	varchar(2)	string	PK	countries		Y
OMP_02	AssessmentMethodId	varchar(50)	string	PK			Y
OMP_03	Start	datetime	datetime	PK			Y
OMP_04	LowerRange	int	numeric	PK			Y
OMP_05	PollutantId	int	numeric		pollutant		Y
OMP_06	End	datetime	datetime				Y
OMP_07	Value	decimal(10,2)	numeric				Y
OMP_08	Unit	varchar(10)	string		concentration		Y
OMP_09	Validity	int	numeric		observationvalidity		Y
OMP_10	Verification	int	numeric		observationverification		Y
OMP_11	TimeResolution	varchar(10)	string		primaryObservation		Y
OMP_12	ResultTime	datetime	datetime				Y
OMP_13	UpperRange	int	numeric				Y
OMP_14	Temperature	decimal(5,2)	numeric				Y
OMP_15	RelativeHumidity	decimal(5,2)	numeric				Y
OMP_16	Pressure	decimal(5,2)	numeric				Y
OMP_17	Inversion	varchar(20)	string		PNSDinversion		Y

Attribute details 

OMP_01 - CountryCode 

Content

Country or territory ISO2 code.

In Reporting

Y

OMP_02 - AssessmentMethodId 

Content

Identifier of the assessment method (sampling point), given by data provider.

Remarks

It will be cross-checked against the SamplingPoint table.

In Reporting

Y

OMP_03 - Start 

Content

Start date and time of the measurement period.

Remarks

Start must be provided with time zone information.

In Reporting

Y

OMP_04 - LowerRange 

Content

Lower range of PNSD bin.

In Reporting

Y

OMP_05 - PollutantId 

Content

Code of the air pollutant being measured, as per Data Dictionary standards.

Remarks

End must be provided with time zone information.

In Reporting

Y

OMP_06 - End 

Content

End date and time of the measurement period.

In Reporting

Y

OMP_07 - Value 

Content

Measured concentration or level of the air pollutant.

In Reporting

Y

OMP_08 - Unit 

Content

Unit of measurement for the air pollution level (e.g., µg/m³).

In Reporting

Y

OMP_09 - Validity 

Content

Indicator of whether the measurement data is valid or not.

In Reporting

Y

OMP_10 - Verification 

Content

Information based on verification flags found in reported time series.

In Reporting

Y

OMP_11 - TimeResolution 

Content

Time resolution of the reported measurement observations (e.g., hourly, daily).

In Reporting

Y

OMP_12 - ResultTime 

Content

Time at which the result was generated or recorded.

In Reporting

Y

OMP_13 - UpperRange 

Content

Upper range of PNSD bin.

In Reporting

Y

OMP_14 - Temperature 

Content

Temperature measured along tihe PNSD (deg Celsius).

In Reporting

Y

OMP_15 - RelativeHumidity 

Content

Relative humidity measured along tihe PNSD (%).

In Reporting

Y

OMP_16 - Pressure 

Content

Pressure measured along tihe PNSD (hPa).

In Reporting

Y

OMP_17 - Inversion 

Content

Inversion method used by country (code list flag).

In Reporting

Y
