MeasurementStation
Attributes
Attribute Code |
Attribute Name |
SQL DB Data Type |
ReportNet3 Data Type |
Properties |
Code list |
Related table(s) |
In Reporting |
|---|---|---|---|---|---|---|---|
STA_01 |
CountryCode |
varchar(2) |
string |
PK |
|||
STA_02 |
StationEoICode |
varchar(10) |
string |
PK |
SamplingPoint |
||
STA_10 |
ReportingTime |
datetime |
datetime |
PK |
N |
||
STA_03 |
NetworkId |
varchar(50) |
string |
||||
STA_04 |
NetworkName |
varchar(150) |
string |
||||
STA_05 |
NetworkOrganisationalLevel |
varchar(20) |
string |
||||
STA_06 |
Timezone |
varchar(20) |
string |
||||
STA_07 |
StationNationalCode |
varchar(50) |
string |
||||
STA_08 |
StationName |
varchar(50) |
string |
||||
STA_09 |
NetworkDocumentId |
varchar(150) |
string |
Documentation |
|||
STA_11 |
Country |
varchar(20) |
string |
N |
|||
STA_12 |
City |
N |
|||||
STA_13 |
CityCode |
N |
|||||
STA_14 |
Deletion |
bit |
boolean |
N |
Note
ReportingTime, Country, City, CityCode and Deletion are Reference attributes without a corresponding attribute in the reporting data model.
Attribute details
STA_01 - CountryCode
Content
Country or territory ISO2 code.
In Reporting
STA_02 - StationEoICode
Content
EoI (Exchange of Information) code of the air quality measurement station, as in AirBase, either re-used or given by data provider following strict rules.
Code list / reference
There will be no specific code list in Data Dictionary but the Station table in reference data flow will serve as code list for AirQualityStationEoICode values.
Remarks
StationEoICode must be always provided and cannot be modified.
Station will become inactive if all sampling points in that station are inactive.
The same Station can become active again if there are new active sampling points or existing sampling points become active again.
In Reporting
STA_10 - ReportingTime
Content
Date and time when the information is submitted..
In Reporting
N - No corresponding reporting attribute.
STA_03 - NetworkId
Content
Identifier of the air quality network, given by data provider.
In Reporting
STA_04 - NetworkName
Content
Name of the air quality measurement network, given by data provider.
In Reporting
STA_05 - NetworkOrganisationalLevel
Content
Level of administration or organization responsible for the air quality network (national, regional, local).
In Reporting
STA_06 - Timezone
Content
Time zone in which air quality measurements and statistics are recorded.
Remarks
TimeZone must be provided and will be used for calculations of AQ statistics.
If TimeZone is modified, all statistics will be recalculated accordingly.
In Reporting
STA_07 - StationNationalCode
Content
National code of the air quality measurement station, given by data provider.
In Reporting
STA_08 - StationName
Content
Name of the air quality measurement station.
In Reporting
STA_09 - NetworkDocumentId
Content
Identifier of the documentation on network and station.
In Reporting
STA_11 - Country
Content
Name of the country.
In Reporting
N - No corresponding reporting attribute.
STA_12 - City
In Reporting
N - No corresponding reporting attribute.
STA_13 - CityCode
In Reporting
N - No corresponding reporting attribute.
STA_14 - Deletion
Content
Flag to indicate that this element must be deleted..
In Reporting
N - No corresponding reporting attribute.
