SamplingPointLocation

Attributes 

Attribute Code	Attribute Name	SQL DB Data Type	ReportNet3 Data Type	Properties	Code list	Related table(s)	In Reporting
SPL_01	CountryCode	varchar(2)	string	PK			Y
SPL_02	AssessmentMethodId	varchar(50)	string	PK		ComplianceAssessmentMethod SamplingPoint SamplingProcess ObservationMeasurementResult	Y
SPL_03	LocationBegin	datetime	datetime	PK			Y
SPL_04	LocationEnd	datetime	datetime				Y
SPL_05	StationArea	varchar(100)	string		areaclassification		Y
SPL_06	SamplingPointCategory	varchar(50)	string		Code list to be developed		Y
SPL_07	Hotspot	bit	boolean				Y
SPL_08	Supersite	bit	boolean				Y
SPL_09	Latitude	decimal(8,4)	numeric				Y
SPL_10	Longitude	decimal(8,4)	numeric				Y
SPL_11	Altitude	decimal(10,1)	numeric				Y
SPL_12	InletHeight	decimal(10,1)	numeric				Y
SPL_13	BuildingDistance	decimal(10,1)	numeric				Y
SPL_14	KerbDistance	decimal(10,1)	numeric				Y
SPL_15	EmissionSourceDistance	decimal(10,1)	numeric				Y
SPL_16	Country	varchar(20)	string				N
SPL_17	X	bigint	numeric				N
SPL_18	Y	bigint	numeric				N
SPL_19	GridNum10m	bigint	numeric				N
SPL_20	GridNum100m	bigint	numeric				N
SPL_21	GridNum1km	bigint	numeric				N
SPL_22	GridNum10km	bigint	numeric				N
SPL_23	Deletion	bit	boolean				N
SPL_24	SamplingPointType	varchar(20)	string				N

Note

Country, X, Y, GridNum10m, GridNum100m, GridNum1km, GridNum10km, Deletion and SamplingPointType are Reference attributes without a corresponding attribute in the reporting data model.

Attribute details 

SPL_01 - CountryCode 

Content

Country or territory ISO2 code.

In Reporting

Y – View reporting attribute

SPL_02 - AssessmentMethodId 

Content

Identifier of the assessment method (sampling point), given by data provider.

In Reporting

Y – View reporting attribute

SPL_03 - LocationBegin 

Content

Start time of the location characteristic(s)

Remarks

The permissible modifications in the location characteristics will be verified by adequate QC.

In Reporting

Y – View reporting attribute

SPL_04 - LocationEnd 

Content

End time of the location characteristic(s)

In Reporting

Y – View reporting attribute

SPL_05 - StationArea 

Content

Classification of the air quality measurement station’s area (urban, suburban, rural, etc.).

Remarks

A change in station area implies closing the associated sampling points by ending the SamplingProcess, declaring a new station and the associated new sampling points.

In Reporting

Y – View reporting attribute

SPL_06 - SamplingPointCategory 

Content

Intention or reason for placing sampling point.

Code list / reference

Code list to be developed.

Remarks

Potential categories: traffic, background, industrial, port, airport, residential heating, multisource.

In Reporting

Y – View reporting attribute

SPL_07 - Hotspot 

Content

Indicator if the measurement site is considered as a hotspot.

Remarks

Y/N.

Hotspot relates to the provisions of the recasted Air Quality Directive 2024/2881, Article 4(27) and others.

In Reporting

Y – View reporting attribute

SPL_08 - Supersite 

Content

Indicator if the measurement site is classified as a “Super Site” for advanced monitoring.

Remarks

Y/N.

In Reporting

Y – View reporting attribute

SPL_09 - Latitude 

Content

Latitude coordinate of the air quality station location (decimal degrees).

In Reporting

Y – View reporting attribute

SPL_10 - Longitude 

Content

Longitude coordinate of the air quality station location (decimal degrees).

In Reporting

Y – View reporting attribute

SPL_11 - Altitude 

Content

Altitude of the air quality station location in meters above sea level.

In Reporting

Y – View reporting attribute

SPL_12 - InletHeight 

Content

Height of the sampling inlet where air quality measurements are taken (in meters).

In Reporting

Y – View reporting attribute

SPL_13 - BuildingDistance 

Content

Horizontal distance from the sampling inlet to the nearest building (in meters).

In Reporting

Y – View reporting attribute

SPL_14 - KerbDistance 

Content

Horizontal distance from the sampling inlet to the nearest road kerb (in meters).

In Reporting

Y – View reporting attribute

SPL_15 - EmissionSourceDistance 

Content

Horizontal distance from the main emission source (in meters).

In Reporting

Y – View reporting attribute
