SRSGrid
Attributes
Attribute Code |
Attribute Name |
SQL DB Data Type |
ReportNet3 Data Type |
Properties |
Code list |
Related table(s) |
In Reporting |
|---|---|---|---|---|---|---|---|
SRG_01 |
CountryCode |
varchar(2) |
string |
PK |
N |
||
SRG_02 |
SRSApplicationId |
varchar(50) |
string |
PK |
N |
||
SRG_03 |
X |
bigint |
numeric |
PK |
N |
||
SRG_04 |
Y |
bigint |
numeric |
PK |
N |
||
SRG_05 |
Area |
??? |
??? |
N |
|||
SRG_06 |
Country |
varchar(20) |
string |
N |
|||
SRG_07 |
GridNum10m |
bigint |
numeric |
N |
|||
SRG_08 |
GridNum100m |
bigint |
numeric |
N |
|||
SRG_09 |
GridNum1km |
bigint |
numeric |
N |
|||
SRG_10 |
GridNum10km |
bigint |
numeric |
N |
|||
SRG_10 |
Deletion |
bit |
boolean |
N |
Note
There is no corresponding table in the reporting data model. Therefore, all attributes are marked N.
Attribute details
SRG_01 - CountryCode
Content
Country or territory ISO2 code.
In Reporting
N - No corresponding reporting table.
SRG_02 - SRSApplicationId
Content
Identifier of the specific spatial representativeness given by data provider.
In Reporting
N - No corresponding reporting table.
SRG_03 - X
Content
X-coordinate of the modeled data point in a projected coordinate reference system.
In Reporting
N - No corresponding reporting table.
SRG_04 - Y
Content
Y-coordinate of the modeled data point in a projected coordinate reference system.
In Reporting
N - No corresponding reporting table.
SRG_05 - Area
Content
???
In Reporting
N - No corresponding reporting table.
SRG_06 - Country
Content
Name of the country.
In Reporting
N - No corresponding reporting table.
SRG_07 - GridNum10m
Content
Grid cell identifier in the EEA grid according to spatial resolution
In Reporting
N - No corresponding reporting table.
SRG_08 - GridNum100m
Content
Grid cell identifier in the EEA grid according to spatial resolution
In Reporting
N - No corresponding reporting table.
SRG_09 - GridNum1km
Content
Grid cell identifier in the EEA grid according to spatial resolution
In Reporting
N - No corresponding reporting table.
SRG_10 - GridNum10km
Content
Grid cell identifier in the EEA grid according to spatial resolution
In Reporting
N - No corresponding reporting table.
SRG_10 - Deletion
Content
Flag to indicate that this element must be deleted.
In Reporting
N - No corresponding reporting table.
