ZoneGeometry

Attributes 

Attribute Code	Attribute Name	SQL DB Data Type	ReportNet3 Data Type	Properties	Code list	Related table(s)	In Reporting
ZGE_01	CountryCode	varchar(2)	string	PK	countries		Y
ZGE_02	ZoneId	varchar(20)	string	PK		AssessmentRegimeZone	Y
ZGE_04	ZoneGeometry	???	???				N
ZGE_03	ZoneGeometryGeoJson	varbinary	geometry				Y
ZGE_05	Country	varchar(20)	string				N
ZGE_06	Deletion	bit	boolean				N

Note

ZoneGeometry, Country and Deletion are Reference attributes without a corresponding attribute in the reporting data model.

Attribute details 

ZGE_01 - CountryCode 

Content

Country or territory ISO2 code.

In Reporting

Y – View reporting attribute

ZGE_02 - ZoneId 

Content

Identifier of the air quality zone, given by data provider.

In Reporting

Y – View reporting attribute

ZGE_04 - ZoneGeometry 

Content

???

In Reporting

N - No corresponding reporting attribute.

ZGE_03 - ZoneGeometryGeoJson 

Content

Geospatial representation of the air quality zone (e.g., polygon geometry).

Remarks

It is allowed to report zone geometries in coordinate systems with the following EPSG codes:

3035,
4258,

In Reporting

Y – View reporting attribute

ZGE_05 - Country 

Content

Name of the country.

In Reporting

N - No corresponding reporting attribute.

ZGE_06 - Deletion 

Content

Flag to indicate that this element must be deleted.

In Reporting

N - No corresponding reporting attribute.
