ModelObjectiveEstimation
Attributes
Attribute Code |
Attribute Name |
SQL DB Data Type |
ReportNet3 Data Type |
Properties |
Code list |
Related table(s) |
In Reporting |
|---|---|---|---|---|---|---|---|
MOE_01 |
CountryCode |
varchar(2) |
string |
PK |
|||
MOE_02 |
AssessmentMethodId |
varchar(50) |
string |
PK |
ComplianceAssessmentMethod |
||
MOE_03 |
DataAggregationProcessId |
varchar(50) |
string |
PK |
MOEResultInline |
||
MOE_04 |
AssessmentMethodName |
varchar(150) |
string |
||||
MOE_05 |
PollutantId |
int |
numeric |
||||
MOE_06 |
ResultEncoding |
varchar(10) |
string |
||||
MOE_07 |
MethodApplication |
varchar(20) |
string |
||||
MOE_08 |
GenericMQI |
decimal(5,2) |
numeric |
||||
MOE_09 |
DataQualityDocumentId |
varchar(150) |
string |
Documentation |
|||
MOE_10 |
MethodDocumentId |
varchar(150) |
string |
Documentation |
|||
MOE_11 |
Country |
varchar(20) |
string |
N |
|||
MOE_12 |
Pollutant |
varchar(50) |
string |
N |
|||
MOE_13 |
DataAggregationProcess |
varchar(XXX) |
string |
N |
|||
MOE_14 |
Deletion |
bit |
boolean |
N |
Note
Country, Pollutant, DataAggregationProcess and Deletion are Reference attributes without a corresponding attribute in the reporting data model.
Attribute details
MOE_01 - CountryCode
Content
Country or territory ISO2 code.
In Reporting
MOE_02 - AssessmentMethodId
Content
Identifier of the assessment method (model), given by data provider.
Remarks
AssessmentMethodId which is model or OBE identifier is understood as an application of modelling or estimation methodology. It may be re-used for different years if the methodology and data sources remain the same (for example when the same source of meteorological data is used with data from different years).
In Reporting
MOE_03 - DataAggregationProcessId
Content
Identifier for the process of data aggregation into statistical values.
Remarks
Several different statistics may be generated by the same AssessmentMethodId (for example where time series are modelled and subsequently aggregated).
In Reporting
MOE_04 - AssessmentMethodName
Content
Name of model or OBE which can be re-used with different AssessmentMethodId, e.g. ‘CHIMERE’, ‘WRF-Chem’, etc.
Remarks
Examples include model names such as ‘CHIMERE’, ‘WRF-Chem’, etc.
In Reporting
MOE_05 - PollutantId
Content
Code of the air pollutant being measured, as per Data Dictionary standards.
Remarks
Only one pollutant can be handled by a single AssessmentMethodId (model/OBE).
In Reporting
MOE_06 - ResultEncoding
Content
Encoding method used for model results (‘zone’, ‘internal’ or ‘external’).
Remarks
Allowed values include:
zone
inline
external
In Reporting
MOE_07 - MethodApplication
Content
Purpose of the model application (e.g., assessment, adjustment, scenario, spatial representativeness)
Remarks
The same Model/OBE identifier can only have one MethodApplication.
In Reporting
MOE_08 - GenericMQI
Content
Modelling Quality Indicator
Remarks
MQI is reported here because it may originate from model or OBE validation exercises not directly related to the area for which modelling results are submitted within AQ e-Reporting. It is considered general information describing the quality of the modelling application used in the reporting.
In Reporting
MOE_09 - DataQualityDocumentId
Content
Identifier of the report describing the model given by data provider.
In Reporting
MOE_10 - MethodDocumentId
Content
Identifier of the report detailing the quality of the modelled data given by data provider.
In Reporting
MOE_11 - Country
Content
Name of the country.
In Reporting
N - No corresponding reporting attribute.
MOE_12 - Pollutant
Content
Name of the air pollutant being measured, as per Data Dictionary standards.
In Reporting
N - No corresponding reporting attribute.
MOE_13 - DataAggregationProcess
Content
Label of the process of data aggregation into statistical values.
In Reporting
N - No corresponding reporting attribute.
MOE_14 - Deletion
Content
Flag to indicate that this element must be deleted.
In Reporting
N - No corresponding reporting attribute.
