SpatialRepresentativeness

Attributes 

Attribute Code	Attribute Name	SQL DB Data Type	ReportNet3 Data Type	Properties	Code list	Related table(s)	In Reporting
SRS_01	CountryCode	varchar(2)	string	PK	countries		Y
SRS_02	SRSId	varchar(50)	string	PK		ComplianceAssessmentMethod	Y
SRS_03	SRSApplicationId	varchar(50)	string	PK		SRSInline SRSExternal	Y
SRS_04	SRSApplication	varchar(50)	string		SRapplication		Y
SRS_05	ResultEncoding	varchar(10)	string		resultencoding		Y
SRS_06	RepresentativenessAssessmentMethodId	varchar(50)	string			ModelObjectiveEstimation	Y
SRS_07	Country	varchar(20)	string				N
SRS_08	Deletion	bit	boolean				N

Note

Country and Deletion are Reference attributes without a corresponding attribute in the reporting data model.

Attribute details 

SRS_01 - CountryCode 

Content

Country or territory ISO2 code.

In Reporting

Y – View reporting attribute

SRS_02 - SRSId 

Content

Identifier of the area representing the sampling point’s measurement spatial coverage or the extent of the exceedance, given by data provider.

In Reporting

Y – View reporting attribute

SRS_03 - SRSApplicationId 

Content

Identifier pointing to the specific spatial representativeness given by data provider.

Remarks

The same SRSId can have several SRSApplication_Id (e.g. one for the SPO representativeness area and one for the exceedance extent).

In Reporting

Y – View reporting attribute

SRS_04 - SRSApplication 

Content

Application of spatial representativeness (SPO representativeness or the exceedance extent).

Remarks

New code list (SPO representativeness area, exceedance extent area).

In Reporting

Y – View reporting attribute

SRS_05 - ResultEncoding 

Content

Encoding method used for model results (‘internal’ or ‘external’).

In Reporting

Y – View reporting attribute

SRS_06 - RepresentativenessAssessmentMethodId 

Content

Identifier of the assessment method (model) used for defining the area (either representativeness or extent), given by data provider.

Remarks

AssessmentMethodId is a model or OBE identifier that points to the method (model/OBE in the Model table) which was used for the assessments of the SPO representativeness area or the exceedance extent.

In Reporting

Y – View reporting attribute

SRS_07 - Country 

Content

Name of the country.

In Reporting

N - No corresponding reporting attribute.

SRS_08 - Deletion 

Content

Flag to indicate that this element must be deleted.

In Reporting

N - No corresponding reporting attribute.
